Region Type
Status
Inactive
Line Label
Unknown
Line Label
Pending
Line Label
Active
Line Label
Prohibited, Restricted
Dashed Inact Single Unk Single Pend Triple Act
Warning, Alert, MOA
Dashed Inact Single Unk Single Pend Triple Act
TFR
Dashed N/A N/A N/A Single N/A Triple N/A
N/A
600-00105-000 Rev 01 -35- FlightMax EX5000
Appendix - Tables
Table 5: SUA and TFR Status
NOTE: For adjacent or overlaying types of Special Use Airspace (e.g. Restricted Areas
or Prohibited Areas within larger MOAs), some masking of the border lines may occur.
Pilots must reference current aeronautical charts for accurate boundaries.
Line Color Type Label
Bright blue Mountain AIRMET MTN
Dark yellow IFR AIRMET IFR
Orange Turbulence AIRMET TURB
Blue Icing AIRMET ICE
Dark red SIGMET AIRMET SIG
Blue gray Convective SIGMET CSIG
Table 6 : AIRMET and SIGMET Boundaries
