Required (Included):
• RATH Call Commander (Part #s: 3200S,
3200F, or 3200D)
• USB programming cable
• USB ash drive with Congurator
Software
• AC power cable
• 4-pin loop connectors
• 2-pin phone line connector
Page 3
Pre-Installation Requirements
3200S/F
3200D
3300FSN 1000 66120
RP7500094B
Required (Not Included) Sold Separately:
• RATH 3300 Series Call Boxes (Available from RATH by AVIRE)
• Power supply with battery backup (Part #: 1000) (Available from RATH by AVIRE)
• 18AWG, 4 conductor, 2 pair cable (Available from RATH by AVIRE)
• Plenum Part #: RP7500094B
• 2 Hour Fire-Rated Part #: 66120
• 120vac power
• Multimeter
• Windows based laptop (Windows 7 or greater required)
• Dedicated external phone line (if the system needs the ability to call o site)
• Analog, Digital, VoIP, and Cellular (Rath Part Number 2100-LTEGSM4 and
2100-LTEVER4) supported.
NOTE: If using VoIP it must be converted to analog before connecting to the system.
