AVIRE RATH SmartCommand 3200S - BOSS Internal Overview

Brains of Smart System (BOSS) Internal Overview
BOSS Controller:
External
Telephone
Line
Call
Commander
Call
Boxes
NOTE: To expose these connections, remove the two screws on the front of the housing to remove
the cover.
Page 4
Call Box:
Call Commander:
Loop In / Out
Loop In / Out
Loop In / Out
Loop In / Out
