AVL DiTEST MCS 120
Commissioning
User Manual
21
2. Take the basic device (2) from the transport / adapter case (1) and put it as
shown right beside the case (3).
Fig. 3-2 MCS 120
3. Connect the MCS 120 to the tester via an USB-cable.
Make sure that the screw cap on the USB Rugged plug (1) is tight.
Fig. 3-3 MCS 120
1 2
2
1
