8. The next screen guides you through the connection process.
It is important to do all connecting work in the shown order.
Execute pt. 2 and 3 in the shown order!
When connecting the cell module, make sure the IR temperature
sensor is not covered and ensure direct visibility between the
sensor and the module.
9. Continue by clicking F8 Next.
Click on the button to get a picture schowing where to connect the cable.
Fig. 4-5 Screen „Connecting cell module“
Caution, all contact surfaces must be clean.
After connecting, ensure that all cables are firmly fixed.
