21
Maintenance
AVL 415SE Smoke Meter Maintenance Guide
1.....Twin-sided adhesive film
2.....Clamping lever roll
3.....Axis II
4.....Roll I (2x)
5.....White value sheet
Fig. 3 Lubricating points on clamping lever
Pos 040
Pos 010
Pos 020
==
Pos 030
1
1
5
2
3
4
Lube points
Lube points
Lube points
Information
These points on the clamping lever only need to be lubricated "sparingly"
approx. every 50 paper rolls.
Please remove any unnecessary or excess oil or grease.
