AVL 415SE User Manual

Maintenance
16
AVL 415SE Smoke Meter — Maintenance Guide
2.3 Components
2.3.1 Disposal Instructions
Adjustment of the
transport paper
mechanism
Every 1 000
operating hours.
Function check and
adjustment is neces-
sary every time spare
parts are exchanged.
Clean disassembled
parts in ultrasonic bath
or replace them.
– Section Suction
Unit on page 24
Adjustment of the
slip clutch
Every 1 000
operating hours
or once a year.
Check the tension and
adjust if necessary.
– Section Filter
Paper Transport
and Spool Device
on page 32
Ratchet clip Every 300 operating
hours.
Every 6 months .
Visual check and
clean if necessary.
When ratchet clip
rolls damaged or
deformed.
Section Clamping
Lever and Ratchet
Clip on page 28
Pump Every 1 000
operating hours.
Every 2 000 - 3 000
operating hours.
Flow check.
Check and replace if
necessary.
Every
2 000 - 3 000
operating hours.
Section Pump on
page 34
Electrical boards Once a year
or if contaminated.
Visual check.
Clean with
compressed air.
––
Compressed air
supply
After each installa-
tion
or once a year.
Visual check.
Replace the filters if
necessary.
Filter change:
once a year for oil
free compressors,
much more often
for oil free
compressors with
oiled air.
See Fig. 29 on
page 35
Pressure reduction
assembly
Once per week
or after assembly.
Check and adjust if
necessary.
–
Component / Test Lifetime /
Service interval
Maintenance Replacement Procedure
Tab. 2
NOTICE
Dispose of used filter paper rolls, fine filters, hose connectors and chemical
agents (e.g. bonding agents or sprays) in accordance with the statutory require-
ments applicable in your country.
Remember that hoses and hose connectors contain fluorine. Observe the statu-
tory requirements in your country when you wish to dispose of this product or
components thereof (e.g. directives on the disposal of electronic waste).
Observe the handling instructions, application notes, storage and transport
instructions, instructions for disposal, and safety instructions of the products as
well as the country-specific regulations.
All appliances have to be treated as hazardous waste. For detailed information
on disposal instructions see the AVL 415SE Product Guide.
