Parts Lists
44
AVL 415SE Smoke Meter — Maintenance Guide
4.3 Spare Parts
Designation Material
Number
Sales Unit
Transport Roll YM3687 PCS
Damper 1 4152W03./C00.0 MY0163 PCS
Damper 2 4152W04./C00.0 MY0164 PCS
Bearing Bush 4152X33./C00.0 YM3494 PCS
Ratchet Clip Roll 4152X63./C00.0 YM3804 PCS
Ratchet Clip Shaft 4152X61./C00.0 YM3802 PCS
Roll Holder 130 4152U26./C00D1 ZG2456 PCS
Roll Holder 250 4152U14./C00.0 ZG2374 PCS
Cable Power/Error 4152V09./C00.0 BV2243 PCS
Cable Heating Orifice 4152V26./C00.0 BV2340 PCS
Cable Heating Orifice 100/115 VAC 4152V27./C00.0 BV4369 PCS
Cable Heating Dev. 230 VAC BV2341SP PCS
Cable Heating Dev. 115 VAC 4152V29./C00.0 BV2344 PCS
Set of Cables 2 4152V43./C00.0 BV2624 PCS
Pl. Connection Cover Cap for Cable Sockets EU1459 PCS
Mains Supply Filter 230V 12A EI0297 PCS
Pl. Connection 3P Built-In Mains Plug EU0013 PCS
Pl. Connection Cover Cap for Appl. Plug EU0339 PCS
Pl. Connection Cover Cap for Appl. Socket EU2031 PCS
Varistor Module 4152.80./C00.0 BO3613 PCS
Push Button, 1xS, 250 V/1 A, Grey ES0419 PCS
Supplementary Equipment Set 4080W01./C00.0 BO3776 PCS
Fuse 1,6 A 250 V EV0044 PCS
Screw Cap 409.08.02 YM0847SP PCS
Measuring Head No. 1 687 224 606 EZ0104SP PCS
Press Fit Bush (Bear.-Clamp.Lever Unit) DL0066SP PCK 2
Pressure Sensor 26PCCFA1D +/-1.034 bar EZ0157SP PCS
Display Board 4070L01./C00.0 BB0429SP PCS
Suction Unit 4152W15./C00.0 BO3774SP PCS
Solenoid Valve 2/2-W G1/8" DN=4 1.8 bar MM0623SP PCS
Solenoid Valve 3/2-W G1/8 DN2.4 1.8 bar MM0624SP PCS
Diaphragm Pump Type 7015ZV/24 VDC MV0207SP PCS
Orifice 4152X02./C00.0 YM3433SP PCS
Holder White Value 4070S10./R34.0 YM2039SP PCK 5
White Lever Panel complete 4152X28./C00.0 BO3582SP PCS
Clutch Disc D=45,D=18 4152X47./C00.0 YM3566SP PCK 10
Straight Connection SO 21121-6-1/8 DN1469SP PCK 5
Kink Protection (Sampling Line) EP0377SP PCK 5
Sampling Probe 415 Straight 4152W05./C00.0 BO3144SP PCS
Sampling Probe 415 Long 4152W30./C00.0 BO4260SP PCS
