T-Muff Screw Connection (Male) TES6/R1/8 DN0815SP PCK 10
Angle Muff Screw Connection (Male) WES/6R1/8 DN0816SP PCK 10
Straight Muff Screw Connection (Male) GES4R1/8 DN1448SP PCK 10
Straight Muff Screw Connection (Male) GES6/R1/8 DN0811SP PCK 10
Socket 5056-09 DN1332SP PCS
Coupling Plug 5150-1/8 DN2161SP PCS
Screw Plug S2610-1/8 DN2165SP PCS
Safety Guard for Fan EI0359SP PCS
Glow Lamp Green 110 V (Status Lamp) EL0325SP PCS
Power Supply 24 V/6,3 A 150 W 85-264 VAC EN0406SP PCS
Relais-Power 4U 24VG 1500 VA 250 V 6 A ER0242SP PCS
Main Switch 2K 380 V/10 A ES0360SP * PCS
Micro Switch, Front Door ES0400SP PCK 2
Fuse 200MA Flink 250 V EV0055SP PCK 10
Temp. Click 80 °C Self Reset EV0245SP PCS
Temp. Click 150 °C Self Reset EV0246SP PCS
Temp. Click 120 °C Mech. Reset EV0247SP PCS
2/2-Way-Valve MM0956SP PCS
Muffler Filter 2941-1/8" MY0162SP PCK 10
Tube 4.0 x 1.0 Teflon 9 bar/150 °C SS0265SP PCK 10
Insulating Mat (Heated) ZG8447SP PCS
Metal Hose NW = 5 L = 500 4152W49 YM4256SP PCS
Gasket 409.01.18 DN0061SP PCK 10
Lock Nut YM1863
Taper Disk YM1864
Hose Nippel with Nut for 415S G01, G02 and 415SE (Stainless Steel) YM3493
Hose Nippel with Nut for 415S G02 and 415SE (Stainless Steel) YM7144
Interface Board BB1718
Controller Board BB1663
LED Panel + Board BB1746
LED Board (at controller)
+ Cable
BB1747
+ BV4090
Rotary Position Transducer Cable BV4667
Hose Clamp DN1080
Jumper EU0494
Tygon R 3400 Hose By The Meter (6.4 x 11 mm) SS0614
Tygon R 3400 Hose By The Meter (4 x 7.2 mm) SS0615
Option RSI
RSI Interface Internal BB1745
Flash Card incl. FW XF0458
Cable BV4689
Option Shop Air
Shop Air Connection (Coupling) DN1812
Pressure Switch 1 bar BW5130SP
Designation Material
Number
Sales Unit
