Avnet MicroZed - Page 13

30-Oct-2020, Rev. 1.1
12
JH6-7 P
Pin 9
JX2, pin 82
Bank 35,L14
JH6-7 N
Pin 10
JX2, pin 84
Bank 35,L15
Pmod™
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JK
Pmod™
JK0-1 P
Pin 1
JX1, pin 61
Bank 34, Y18
JK0-1 N
Pin 2
JX1, pin 63
Bank 34, Y19
JK2-3 P
Pin 3
JX1, pin 62
Bank 34, V16
JK2-3 N
Pin 4
JX1, pin 64
Bank 34, W16
JK4-5 P
Pin 7
JX1, pin 81
Bank 34, N17
JK4-5 N
Pin 8
JX1, pin 83
Bank 34, P18
JK6-7 P
Pin 9
JX1, pin 74
Bank 34, P15
JK6-7 N
Pin 10
JX1, pin 76
Bank 34, P16
Pmod™
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JY
Pmod™
JY0-1 P
Pin 1
JX1, pin 87
Bank 13, U7
JY0-1 N
Pin 2
JX1, pin 89
Bank 13, V7
JY2-3 P
Pin 3
JX1, pin 88
Bank 13, T9
JY2-3 N
Pin 4
JX1, pin 90
Bank 13, U10
JY4-5 P
Pin 7
JX1, pin 91
Bank 13, V8
JY4-5 N
Pin 8
JX1, pin 93
Bank 13, W8
JY6-7 P
Pin 9
JX1, pin 92
Bank 13, T5
JY6-7 N
Pin 10
JX1, pin 94
Bank 13, U5
Pmod™
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JZ
Pmod™
JZ0-1 P
Pin 1
JX2, pin 93
Bank 13, Y12
JZ0-1 N
Pin 2
JX2, pin 95
Bank 13, Y13
JZ2-3 P
Pin 3
JX2, pin 94
Bank 13, V11
JZ2-3 N
Pin 4
JX2, pin 96
Bank 13, V10
JZ4-5 P
Pin 7
N/C
--
JZ4-5 N
Pin 8
JX2, pin 97
Bank 13, V6
JZ6-7 P
Pin 9
JX2, pin 99
Bank 13, W6
JZ6-7 N
Pin 10
JX2, pin 100
Bank 13, V5
Pmod™
Carrier
Net Name
Pmod Pin
Number
MIO #
MicroHeader
Connection
Zynq AP SOC
Connection
PS
Pmod™
PMOD_D0
Pin 1
MIO13
JX2, pin 1
Bank 500, E8
PMOD_D1
Pin 2
MIO10
JX2, pin 2
Bank 500, E9
PMOD_D2
Pin 3
MIO11
JX2, pin 3
Bank 500, C6
PMOD_D3
Pin 4
MIO12
JX2, pin 4
Bank 500, D9
PMOD_D4
Pin 7
MIO0
JX2, pin 5
Bank 500, E6
PMOD_D5
Pin 8
MIO9
JX2, pin 6
Bank 500, B5
PMOD_D6
Pin 9
MIO14
JX2, pin 7
Bank 500, C5
PMOD_D7
Pin 10
MIO15
JX2, pin 8
Bank 500, C8
