Pmod™
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JD
Pmod™
JD0-1 P
Pin 1
JX1, pin 67
Bank 34, R16
JD0-1 N
Pin 2
JX1, pin 69
Bank 34,R17
JD2-3 P
Pin 3
JX1, pin 68
Bank 34, T17
JD2-3 N
Pin 4
JX1, pin 70
Bank 34, R18
JD4-5 P
Pin 7
JX1, pin 73
Bank 34, V17
JD4-5 N
Pin 8
JX1, pin 75
Bank 34, V18
JD6-7 P
Pin 9
JX1, pin 74
Bank 34, W18
JD6-7 N
Pin 10
JX1, pin 76
Bank 34, W19
Pmod™
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JE
Pmod™
JE0-1 P
Pin 1
JX2, pin 23
Bank 35, E17
JE0-1 N
Pin 2
JX2, pin 25
Bank 35, D18
JE2-3 P
Pin 3
JX2, pin 24
Bank 35, D19
JE2-3 N
Pin 4
JX2, pin 26
Bank 35, D20
JE4-5 P
Pin 7
JX2, pin 29
Bank 35, E18
JE4-5 N
Pin 8
JX2, pin 31
Bank 35, E19
JE6-7 P
Pin 9
JX2, pin 30
Bank 35, F16
JE6-7 N
Pin 10
JX2, pin 32
Bank 35, F17
Pmod™
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JF
Pmod™
JF0-1 P
Pin 1
JX2, pin 35
Bank 35, M19
JF0-1 N
Pin 2
JX2, pin 37
Bank 35, M20
JF2-3 P
Pin 3
JX2, pin 36
Bank 35, M17
JF2-3 N
Pin 4
JX2, pin 38
Bank 35, M18
JF4-5 P
Pin 7
JX2, pin 41
Bank 35, L19
JF4-5 N
Pin 8
JX2, pin 43
Bank 35, L20
JF6-7 P
Pin 9
JX2, pin 42
Bank 35, K19
JF6-7 N
Pin 10
JX2, pin 44
Bank 35, J19
Pmod™
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JG
Pmod™
JG0-1 P
Pin 1
JX2, pin 61
Bank 35, F19
JG0-1 N
Pin 2
JX2, pin 63
Bank 35, F20
JG2-3 P
Pin 3
JX2, pin 62
Bank 35, G17
JG2-3 N
Pin 4
JX2, pin 64
Bank 35, G18
JG4-5 P
Pin 7
JX2, pin 53
Bank 35, H16
JG4-5 N
Pin 8
JX2, pin 55
Bank 35, H17
JG6-7 P
Pin 9
JX2, pin 54
Bank 35, J18
JG6-7 N
Pin 10
JX2, pin 56
Bank 35, H18
Pmod
Carrier
Net Name
Pmod Pin
Number
MicroHeader
Connection
Zynq AP SOC
Connection
JH
Pmod™
JH0-1 P
Pin 1
JX2, pin 73
Bank 35, H15
JH0-1 N
Pin 2
JX2, pin 75
Bank 35, G15
JH2-3 P
Pin 3
JX2, pin 74
Bank 35, K14
JH2-3 N
Pin 4
JX2, pin 76
Bank 35, J14
JH4-5 P
Pin 7
JX2, pin 81
Bank 35, N15
JH4-5 N
Pin 8
JX2, pin 83
Bank 35, N16
