Avnet MicroZed - Page 16

30-Oct-2020, Rev. 1.1
15
Table 12 – JX1 Connections
Carrier Connection
Carrier
Net Name
MicroHeader
Connection
Zynq AP SOC
Connection
Zynq AP SOC Pin
XADC, pin 1
XADC_V_N
JX1, pin 99
Bank 0, K9
VN_0
XADC, pin 2
XADC_V_P
JX1, pin 97
Bank 0, L10
VP_0
XADC, pin 9
XADC-DX_P
JX1, pin 98
Bank 0, M9
DXP_0
XADC, pin 12
XADC-DX_N
JX1, pin 100
Bank 0, M10
DXN_0
LED0
LED0
JX1, pin 41
Bank 34, U14
IO_L11P_T1_SRCC_34
LED1
LED1
JX1, pin 43
Bank 34, U15
IO_L11N_T1_SRCC_34
LED2
LED2
JX1, pin 42
Bank 34, U18
IO_L12P_T1_MRCC_34
LED3
LED3
JX1, pin 44
Bank 34, U19
IO_L12N_T1_MRCC_34
LED4
LED4
JX1, pin 9
Bank 34, R19
IO_0_34
LED5
LED5
JX1, pin 19
Bank 34, V13
IO_L3N_T0_DQS_34
LED6
LED6
JX1, pin 24
Bank 34, P14
IO_L6P_T0_34
LED7
LED7
JX1, pin 26
Bank 34, R14
IO_L6N_T0_VREF_34
Pmod JA, pin 1
JA0-1 P
JX1, pin 11
Bank 34, T11
IO_L1P_T0_34
Pmod JA, pin 2
JA0-1 N
JX1, pin 13
Bank 34, T10
IO_L1N_T0_34
Pmod JA, pin 3
JA2-3 P
JX1, pin 12
Bank 34, T12
IO_L2P_T0_34
Pmod JA, pin 4
JA2-3 N
JX1, pin 14
Bank 34, U12
IO_L2N_T0_34
Pmod JA, pin 7
JA4-5 P
JX1, pin 18
Bank 34, V12
IO_L4P_T0_34
Pmod JA, pin 8
JA4-5 N
JX1, pin 20
Bank 34, W13
IO_L4N_T0_34
Pmod JA, pin 9
JA6-7 P
JX1, pin 23
Bank 34, T14
IO_L5P_T0_34
Pmod JA, pin 10
JA6-7 N
JX1, pin 25
Bank 34, T15
IO_L5N_T0_34
Pmod JB, pin 1
JB0-1 P
JX1, pin 29
Bank 34, Y16
IO_L7P_T1_34
Pmod JB, pin 2
JB0-1 N
JX1, pin 31
Bank 34, Y17
IO_L7N_T1_34
Pmod JB, pin 3
JB2-3 P
JX1, pin 30
Bank 34, W14
IO_L8P_T1_34
Pmod JB, pin 4
JB2-3 N
JX1, pin 32
Bank 34, Y14
IO_L8N_T1_34
Pmod JB, pin 7
JB4-5 P
JX1, pin 35
Bank 34, T16
IO_L9P_T1_DQS_34
Pmod JB, pin 7
JB4-5 N
JX1, pin 37
Bank 34, U17
IO_L9N_T1_DQS_34
Pmod JB, pin 8
JB6-7 P
JX1, pin 36
Bank 34, V15
IO_L10P_T1_34
Pmod JB, pin 10
JB6-7 N
JX1, pin 38
Bank 34, W15
IO_L10N_T1_34
Pmod JC, pin 1
JC0-1 P
JX1, pin 47
Bank 34, N18
IO_L13P_T2_MRCC_34
Pmod JC, pin 2
JC0-1 N
JX1, pin 49
Bank 34, P19
IO_L13N_T2_MRCC_34
Pmod JC, pin 3
JC2-3 P
JX1, pin 48
Bank 34, N20
IO_L14P_T2_SRCC_34
Pmod JC, pin 4
JC2-3 N
JX1, pin 50
Bank 34, P20
IO_L14N_T2_SRCC_34
Pmod JC, pin 7
JC4-5 P
JX1, pin 53
Bank 34, T20
IO_L15P_T2_DQS_34
Pmod JC, pin 8
JC4-5 N
JX1, pin 55
Bank 34, U20
IO_L15N_T2_DQS_34
Pmod JC, pin 9
JC6-7 P
JX1, pin 54
Bank 34, V20
IO_L16P_T2_34
Pmod JC, pin 10
JC6-7 N
JX1, pin 56
Bank 34, W20
IO_L16N_T2_34
Pmod JD, pin 1
JD0-1 P
JX1, pin 67
Bank 34, R16
IO_L19P_T3_34
Pmod JD, pin 2
JD0-1 N
JX1, pin 69
Bank 34,R17
IO_L19N_T3_VREF_34
Pmod JD, pin 3
JD2-3 P
JX1, pin 68
Bank 34, T17
IO_L20P_T3_34
Pmod JD, pin 4
JD2-3 N
JX1, pin 70
Bank 34, R18
IO_L20N_T3_34
Pmod JD, pin 7
JD4-5 P
JX1, pin 73
Bank 34, V17
IO_L21P_T3_DQS_34
Pmod JD, pin 8
JD4-5 N
JX1, pin 75
Bank 34, V18
IO_L21N_T3_DQS_34
Pmod JD, pin 9
JD6-7 P
JX1, pin 74
Bank 34, W18
IO_L22P_T3_34
Pmod JD, pin 10
JD6-7 N
JX1, pin 76
Bank 34, W19
IO_L22N_T3_34
Pmod JK, pin 1
JK0-1 P
JX1, pin 61
Bank 34, Y18
IO_L17P_T2_34
Pmod JK, pin 2
JK0-1 N
JX1, pin 63
Bank 34, Y19
IO_L17N_T2_34
Pmod JK, pin 3
JK2-3 P
JX1, pin 62
Bank 34, V16
IO_L18P_T2_34
Pmod JK, pin 4
JK2-3 N
JX1, pin 64
Bank 34, W16
IO_L18N_T2_34
Pmod JK, pin 7
JK4-5 P
JX1, pin 81
Bank 34, N17
IO_L23P_T3_34
Pmod JK, pin 8
JK4-5 N
JX1, pin 83
Bank 34, P18
IO_L23N_T3_34
Pmod JK, pin 9
JK6-7 P
JX1, pin 74
Bank 34, P15
IO_L24P_T3_34
Pmod JK, pin 10
JK6-7 N
JX1, pin 76
Bank 34, P16
IO_L24N_T3_34
