Pmod JG, pin 1
JG0-1 P
JX2, pin 62 Bank 35, F19
IO_L15P_T2_DQS_AD12P_3
5
Pmod JG, pin 2
JG0-1 N
JX2, pin 64
Bank 35, F20
IO_L15N_T2_DQS_AD12N_
35
Pmod JG, pin 3
JG2-3 P
JX2, pin 61
Bank 35, G17
IO_L16P_T2_35
Pmod JG, pin 4
JG2-3 N
JX2, pin 63
Bank 35, G18
IO_L16N_T2_35
Pmod JG, pin 7
JG4-5 P
JX2, pin 53
Bank 35, H16
IO_L13P_T2_MRCC_35
Pmod JG, pin 8
JG4-5 N
JX2, pin 55
Bank 35, H17
IO_L13N_T2_MRCC_35
Pmod JG, pin 9
JG6-7 P
JX2, pin 54
Bank 35, J18
IO_L14P_T2_AD4P_SRCC_
35
Pmod JG, pin 10
JG6-7 N
JX2, pin 56
Bank 35, H18
IO_L14N_T2_AD4N_SRCC_
35
Pmod JH, pin 1
JH0-1 P
JX2, pin 74
Bank 35, H15
IO_L19P_T3_35
Pmod JH, pin 2
JH0-1 N
JX2, pin 76
Bank 35, G15
IO_L19N_T3_VREF_35
Pmod JH, pin 3
JH2-3 P
JX2, pin 73
Bank 35, K14
IO_L20P_T3_AD6P_35
Pmod JH, pin 4
JH2-3 N
JX2, pin 75
Bank 35, J14
IO_L20N_T3_AD6N_35
Pmod JH, pin 7
JH4-5 P
JX2, pin 81
Bank 35, N15
IO_L21P_T3_DQS_AD14P_3
5
Pmod JH, pin 8
JH4-5 N
JX2, pin 83
Bank 35, N16
IO_L21N_T3_DQS_AD14N_
35
Pmod JH, pin 9
JH6-7 P
JX2, pin 82
Bank 35,L14
IO_L22P_T3_AD7P_35
Pmod JH, pin 10
JH6-7 N
JX2, pin 84
Bank 35,L15
IO_L22N_T3_AD7N_35
DIP_SW, pin 1
DIP_SW0
JX2, pin 87
Bank 35, M14
IO_L23P_T3_35
DIP_SW, pin 2
DIP_SW1
JX2, pin 89
Bank 35, M15
IO_L23N_T3_35
DIP_SW, pin 3
DIP_SW2
JX2, pin 88
Bank 35, K16
IO_L24P_T3_AD15P_35
DIP_SW, pin 4
DIP_SW3
JX2, pin 90
Bank 35, J16
IO_L24N_T3_AD15N_35
PB, pin 3
PB0
JX2, pin 68
Bank 35, J20
IO_L17P_T2_AD5P_35
PB, pin 3
PB1
JX2, pin 70
Bank 35, H20
IO_L17N_T2_AD5N_35
PB, pin 3
PB2
JX2, pin 67
Bank 35, G19
IO_L18P_T2_AD13P_35
PB, pin 3
PB3
JX2, pin 69
Bank 35, G20
IO_L18N_T2_AD13N_35
BB_CLK_P
BB_CLK_P
JX2, pin 48
Bank 35, K17
IO_L12P_T1_MRCC_35
BB_CLK_P
BB_CLK_P
JX2, pin 50
Bank 35, K18
IO_L12N_T1_MRCC_35
PG_CARRIER
PG_CARRIER
JX2, pin, 11
--
N/C
PB_INIT# 2
INIT#
JX2, pin 9
Bank 0, R10
INIT#
VCCIO_EN
VCCIO_EN
JX2, pin 10
Bank 0, L6
PG_1V8
PS_Pmod, pin 1
PMOD_D0
JX2, pin 1
Bank 500, E8
PS_MIO0_500
PS_Pmod, pin 2
PMOD_D1
JX2, pin 2
Bank 500, E9
PS_MIO9_500
PS_Pmod, pin 3
PMOD_D2
JX2, pin 3
Bank 500, C6
PS_MIO10_500
PS_Pmod, pin 4
PMOD_D3
JX2, pin 4
Bank 500, D9
PS_MIO11_500
PS_Pmod, pin 7
PMOD_D4
JX2, pin 5
Bank 500, E6
PS_MIO12_500
PS_Pmod, pin 8
PMOD_D5
JX2, pin 6
Bank 500, B5
PS_MIO13_500
PS_Pmod, pin 9
PMOD_D6
JX2, pin 7
Bank 500, C5
PS_MIO14_500
PS_Pmod, pin 10
PMOD_D7
JX2, pin 8
Bank 500, C8
PS_MIO15_500
Pmod_JZ,pin 1
JZ0-1 P
JX2, pin 93
Bank 13, Y12
IO_L20P_T3_13
Pmod_JZ,pin 2
JZ0-1 N
JX2, pin 95
Bank 13, Y13
IO_L20N_T3_13
Pmod_JZ,pin 3
JZ2-3 P
JX2, pin 94
Bank 13, V11
IO_L21P_T3_DQS_13
Pmod_JZ,pin 4
JZ2-3 N
JX2, pin 96
Bank 13, V10
IO_L21N_T3_DQS_13
Pmod_JZ,pin 7
JZ4-5 P
N/C
--
--
Pmod_JZ,pin 8
JZ4-5 N
JX2, pin 97
Bank 13, V6
IO_L22P_T3_13
Pmod_JZ,pin 9
JZ6-7 P
JX2, pin 99
Bank 13, W6
IO_L22N_T3_13
Pmod_JZ,pin 10
JZ6-7 N
JX2, pin 100
Bank 13, V5
IO_L6N_T0_VREF_13
** Pmod_JY has only 7 connections, thus cannot connect to QSPI or SD interfaces.
