3.3. FUNCTION SELECTION JUMPERS
The RS232/485, CANBUS, and WATCHDOG have internal jumpers to set bus signaling, termination, function, etc. The
lid must be removed to access these jumpers.
Jumper locations
Detail of J22 jumpers
