96 Avocent PM PDU Installer/User Guide
Appendix C: Replacing the Fuses (For Service Personnel Only)
This product contains replaceable fuses. To avoid serious injury and/or damage to your Avocent
PM PDU, make sure:
• The PDU is disconnected from a power so
urce and all connected devices are turned off before
replacing a fuse.
• Fuses are replaced with an Avocent approved bra
nch circuit fuse class G time delay type with
20A 600 VAC rating.
CAUTION: Avocent recommends using the Avocent fuse replacement kit. Avocent is not responsible for any
issues that may occur using any other vendor’s fuse replacement kit.
• Fuses are replaced by qualified personnel.
• Fuses are denoted with the following markings on the board: FC1-FC2, FC3-FC4, FC5-FC6,
FC7-FC8, FC9-FC1
0, FC11-FC12, FC13-FC14, FC15-FC16, FC17-FC18, FC19-FC20, FC21-
FC22, FC23-FC24, FC1-FC5, FC2-FC6, FC3-FC7, FC4-FC8 . Refer to Appendix B for fuse(s)
to outlet(s) correlation.
WARNING: There is a risk of explosion if the lithium battery is replaced with an incorrect type. Dispose of used
batteries according to the manufacturer’s instructions.
CAUTION: Double pole/neutral fusing.
