14 Avocent PM PDU Installer/User Guide
Figure 3.1: Administrator Web Manager Screen
Wizard Mode
The Wizard mode is designed to simplify the setup and configuration process by guiding an
administrator through the configuration steps. An administrator can configure the Security Profile,
Network and Users Settings using the Wizard.
By default, the first time an administrator accesses the PM PDU through the Web
Manager, the
Wizard will be displayed. Subsequent log-ins will open in Expert mode, and once the PM PDU has
Table 3.1: Web Manager Screen Areas
Number Description
1 Top option bar. The name of the appliance and of the logged in user appear on
the lef
t side.
Refresh, Print, Logout and Help buttons appear on the right.
2 Tab bar. Displays whether the admin is in Expert or Wizard mode.
3 Side Navigation Bar. Menu options for configuration, viewing of system
info
rmation and access to devices. The options change
based on user rights.
4 Content area. Contents change based on the options selected in the side
navigation bar
.
1
2
3
4
