Instructions
This symbol is intended to alert the user to the presence of important opera
ting and maintenance (servicing)
instructions in the literature accompanying the appliance.
Dangerous Voltage
This symbol is intended to alert the user to the presence of unin
sulated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
Power On
This symbol indicates the principal on/off switch is in the on position.
Power Off
This symbol indicates the principal on/off switch is in the off position.
Protective Grounding Terminal
This symbol indicates a terminal which must be co
nnected to earth ground prior to making any other
connections to the equipment.
Functional Earthing Terminal
This symbol indicates a terminal which serves the pu
rpose of establishing chassis ground equal potential.
