2 SwitchView IP 1020 Remote Access Device Installer/User Guide
Figure 1.1: Example SwitchView IP 1020 Remote Access Device Configuration
Table 1.1: Descriptions for Figure 1.1
Number Description
1 Ethernet
2 Analog User
3 Digital User (Computer with Internet browser)
4 SwitchView IP 1020 Remote Access Device
1
4
2
3
