Avocent SwitchView IP 1020 User Manual

Appendices 43
Appendix B: Technical Specifications
Table B.1: SwitchView IP 1020 Remote Access Device Product Specifications
Server Ports
Number 1
Type PS/2, USB
Connectors PS/2, USB, VGA
Sync Types Separate horizontal and vertical
Plug and Play DDC2B
Video Resolution
640 x 480 @ 60 Hz
800 x 600 @ 75 Hz
960 x 700 @ 75 Hz
1024 x 768 @ 75 Hz
1280 x 1024 @ 75 Hz (Remote port maximum)
Supported Cabling CPS2-6A cable, 6 feet
Dimensions
Height x Width x Depth
1.06 in x 8.19 in x 5.25 in
(2.70 cm x 20.80 cm x 13.34 cm)
Weight (without cables) 1.5 lbs (0.68 kg) without cables
Network Connection
Number 1
Type 10/100/1000 Ethernet
Connector RJ-45
Local Port
Number 1
Type PS/2, VGA
Power Consumption 5 W
Operating Voltage external 5 V DC power @ 2.0 A
AC-input Power 10.5 W maximum (120 V, 60 Hz)
AC-input Range 100 - 240 VAC
