Avonic CM7 IP Series User Manual

Camera Control Commands
Command Function Command Packet Comments
CAM_NR(3D)Level - 8x 01 04 54 0p FF p: NR Setting (0: Off,
level 1 to 8)
CAM_Flicker - 8x 01 04 23 0p FF p: Flicker Settings
(0: Off, 1: 50Hz, 2: 60Hz)
CAM_DHotPixel - 8x 01 04 56 0p FF p: Dynamic Hot Pixel Setting (0: 0ff,
level 1 to 5)
Reset 8x 01 04 02 00 FF
Up 8x 01 04 02 02 FF
Down 8x 01 04 02 03 FF
Aperture ControlCAM_Aperture (sharpness)
Direct 8x 01 04 42 00 00 0p 0q FF pq: Aperture Gain
Off 8x 01 04 63 00 FFCAM_PictureEffect
B&W 8x 01 04 63 04 FF
Picture Effect Setting
Reset 8x 01 04 3F 00 pp FF
Set 8x 01 04 3F 01 pp FF
CAM_Memory(preset)
Recall 8x 01 04 3F 02 pp FF
pp: Memory Number (=0 to 127)
On 8x 01 04 61 02 FFCAM_LR_Reverse
Off 8x 01 04 61 03 FF
Image Flip Horizontal On/Off
On 8x 01 04 66 02 FFCAM_PictureFlip
Off 8x 01 04 66 03 FF
Image Flip Vertical On/Off
Freeze ON 8x 04 04 62 02 FF Freeze ON immediately
Freeze OFF 8x 04 04 62 03 FF Freeze OFF immediately
Preset Freeze ON 8x 04 04 62 22 FF Freeze ON when running preset
Freeze
(CM70 series ONLY)
Preset Freeze OFF 8x 04 04 62 23 FF Freeze OFF when running preset
Off 8x 01 06 06 03 FFSYS_Menu
On 8x 01 06 06 02 FF
Turns the OSD menu On/Off
CAM_ColorGain Direct 8x 01 04 49 00 00 00 0P FF p: Color Gain setting
0h (60%) to Eh (200%)
Camera Control Commands
Command Function Command Packet Comments
Pan_tiltDrive Up 8x 01 06 01 VV WW 03 01 FF VV: Pan speed 0x01(low speed) to
0x18 (high speed)
WW: Tilt speed 0x01(low speed) to
0x14 (high speed)
YYYY: Pan Position ZZZZ: Tilt Position
Down 8x 01 06 01 VV WW 03 02 FF
Left 8x 01 06 01 VV WW 01 03 FF
Right 8x 01 06 01 VV WW 02 03 FF
Upleft 8x 01 06 01 VV WW 01 01 FF
Upright 8x 01 06 01 VV WW 02 01 FF
DownLeft 8x 01 06 01 VV WW 01 02 FF
DownRight 8x 01 06 01 VV WW 02 02 FF
Stop 8x 01 06 01 VV WW 03 03 FF
67
