AVS Electronics ONE PA - Comparative Technical Specifications

- 31 -
E
N
G
TECHNICAL CHARACTERISTICS
OnE WS OnE PA OnE PA HP OnE DT OnE DT HP
Nominal voltage 3,6 V = 12 V =
Power supply voltage Max: 3,6 V =
Min: 3 V =
Max: 15 V =
Min: 10,5 V =
Max: 15 V =
Min: 10,5 V =
Max: 15 V =
Min: 10,5 V =
Max: 15 V =
Min: 10,5 V =
Absorption
25 µA in quiet
20 mA in alarm
25 mA in quiet
28 mA in alarm
30 mA in quiet
33 mA in alarm
30 mA in quiet
33 mA in alarm
30 mA in quiet
33 mA in alarm
Coverage 10° on 8 effective metres 10° on 12 effective
Infrared anti-masking YES YES YES YES YES
Microwave anti-masking NO NO NO YES YES
Temperature compensation YES YES YES YES YES
Signal emitted by the microwave
- - - Pulsed Pulsed
Microwave frequency - - - 24 GHz 24 GHz
Transmission frequency FM 868 MHz - - - -
RS485 serial connection
NO NO
YES, with Xtream
controllers and
XSATHP
satellites
NO
YES, with Xtream
controllers and
XSATHP
satellites
Range in open field ~ 150 m. - - - -
Low-battery signal: YES - - - -
Survival signal YES - - - -
Installation height recommended from 1.9 to 2.2 m
Display through XWIN software NO NO YES NO YES
Management through XWIN software NO NO YES NO YES
Accelerometer YES
Electronic card operating conditions: -25° C / + 55° C
Weight 100 g
Dimensions(DxWxH) 44 mm x 40 mm x 123 mm
Protection grade IP54
Rain protection mod. OSC yes (optional)
INSTALLATION AND MAINTENANCE MUST BE PERFORMED BY QUALIFIED PERSONNEL
The power supply must come from a very low voltage safety circuit and having the characteristics of a
limited, fuse-protected power source.
AVS ELECTRONICS Spa reserves the right to make changes at any time without notice.
40 mm
123 mm
64 mm
45 mm
50 mm
42 mm
64 mm
50 mm
45 mm
8 mm
44 mm
The product complies with the CE directive on electromagnetic compatibility.
5 mm
2 mm
