FREQUENTLY-USED FUNCTIONS
23
6) AREA
Click “EDIT” to set the motion detection area.
There are 16 × 12 grids per camera for all channels. Pink blocks represent the area
that is not being detected while the transparent blocks are the area under
detection.
5.5 PTZ Camera Setting
Right-click to display the main menu, and select “ADVANCED CONFIG” “REMOTE”.
ADVANCED CONFIG
C A N E R A CH1 CH2 CH3
X
DETECTION DEVICE PTZ
ALERT ID 00
NETWORK PROTOCOL NORMAL
DISPLAY RATE 2400
RECORD
REMOTE
EXIT
1) DEVICE
For the PTZ camera, select “PTZ”.
2) ID
Click the current value to set the ID number (0 ~ 255) for the connected PTZ
camera if necessary.
Make sure the ID setting of the camera is the same as the setting here, or the DVR
will not be able to control the device.
Note: To know the default ID of the PTZ camera, please refer to its user manual.
3) PROTOCOL
Select NORMAL (our protocol), P-D (PELCO-D) or P-P (PELCO-P) protocol.
4) RATE
Select the baud rate for the connected PTZ camera (2400 / 4800 / 9600 / 19200 /
57600 / 115200).
Make sure the baud rate setting of the camera is the same as the setting here, or
the DVR will not be able to control the device.
Note: To know the default baud rate of the PTZ camera, please refer to its user
manual.
To Next Page
