APPENDIX 1 SPECIFICATIONS
51
For 4CH Model
Model 7
Video System NTSC / PAL (auto detection)
Video Compression Format H.264
Video Input
(composite video signal 1 Vp-p 75Ω BNC)
4 channels
Video Output (BNC) Main Monitor: For stable display
Video Output (VGA) Built-in (Resolution support up to 1600 x 1200)
Audio Input 4 audio inputs
(Mono) Output 1 audio output
Maximum Recording Rate Frame 704×480 pixels with 30 IPS <NTSC> / 704×576 with 25 IPS <PAL>
Field 704×240 pixels with 60 IPS <NTSC> / 704×288 pixels with 50 IPS <PAL>
CIF 352×240 pixels with 120 IPS <NTSC> / 352×288 pixels with100 IPS <PAL>
Image Quality Setting SUPER BEST / BEST / HIGH /NORMAL
Hard Disk Storage** Accommodates 1 SATA HDD
Quick Search Time / Motion / Alarm search mode
SATA Interface Built-in
Recording Mode Manual / Timer / Motion / Alarm / Remote
Multiplex Operation Live display / record / playback / backup / network operations
USB Mouse Control YES
Motion Detection Area 16 × 12 grids per camera for all channels
Motion Detection Sensitivity 3 adjustable parameters for accurate detection
Pre-alarm Recording YES
Backup Device USB 2.0 flash drive / Network
Web Transmitting Compression Format H.264
Ethernet 10/100 Base-T. Supports remote control and live view via Ethernet
CMS:
Our self-developed and free software,
“Video Viewer”
Web Browser:
Internet Explorer, Mozilla Firefox, Google
Chrome & Safari
Media Player: QuickTime
Remote Surveillance
(Operating System:
Windows 7 / Vista / XP / 2000)
Max. on-line user: 10
Network Protocol TCP/IP, PPPOE, DHCP and DDNS
Remote Independent Operation YES
Remote Live Audio YES
Remote Event Download & Playback YES
Event Notification By FTP / E-Mail
IR Remote Control YES (IR receiver built-in)
Mobile Surveillance YES
Picture Zoom 2X digital zoom
PTZ Control YES
Alarm I/O 4 inputs, 1 output
