AXISC1004-ENetworkCabinetSpeaker
VoiceoverIP(VoIP)
1.GotoSetup>VoIP>AccountSettings.
2.ClickAdd.
3.Entertheaccountdetails.
UndertheGeneraltab:
-SeeAccountInformationonpage17.
-SeeAccountCredentialsonpage17.
-SeeSIPServerSettingsonpage17.
UndertheNetworktab:
-SeeTransportSettingsonpage18.
-SeeProxySettingsonpage18.
4.ClickOK.
Toeditanaccount,selecttheaccountintheaccountlistandclickModify.
Toremoveanaccount,selecttheaccountintheaccountlistandclickRemove.
AccountInformation
•Name–Enteradescriptivename.Thiscanforexamplebearstandlastname,arole,oralocation.Thenameisusedas
analiasandisespeciallyusefulwhenseveralaccountshavethesameuserID.
•Defaultaccount–Selecttomakethisthedefaultaccount.Onlyoneaccountcanbethedefaultaccount.
Atstartup,thersttimetheproductisaccessedorafterareset,apeeraccountiscreatedautomaticallyandsettobethe
defaultaccount.Thispeeraccountcanonlyberemovedifatleastonemoreaccounthasbeenaddedtothelist.
ThedefaultaccountwillbeusedwhenmakingaVAPIX
®
ApplicationProgrammingInterface(API)callwithoutspecifying
whichSIPaccounttocallfrom.Formoreinformation,visitwww.axis.com/developer.
AccountCredentials
•UserID–UserIDistypicallytheextensionorphonenumberassignedtotheAxisproductattheSIPserver.Itisalso
possibletouseaSIPURIasaUserIDifrequiredbytheSIPserver.
•AuthenticationID–EntertheAuthenticaionIDusedforauthenticatingagainsttheSIPserver.Thisistypicallythe
sameastheUserID.
•Password–EnterthepasswordassociatedwiththeSIPaccountforauthenticatingagainsttheSIPserver.
•CallerID–ThenamethatispresentedtotherecipientofcallsfromthisAxisproduct.
TocreateanaccountthatisregisteredwithaPBXoraserviceprovider,entertheuserID,password,andtheregistraraddressor
domainname.SeeSIPServerSettingsbelow.IfyouonlyenterauserID,theaccountwillbeusedasapeer-to-peeraccount.
Note
UnlessthedevicesareconnectedtoNATswithSIP-specicportforwardingsuchasSTUNorTURN,theaccountwillonlybe
abletocommunicatewithdevicesthatareconnectedtothesameprivatenetwork.Formoreinformation,seeNetwork
AddressTranslation(NAT)Traversal(portforwarding)onpage15.
SIPServerSettings
•Domainname–Ifavailable,enterthepublicdomainname.ThedomainnamewillbeshownaspartoftheSIPaddress
whencallingotheraccounts.Formoreinformation,seeAboutSIPAddressesonpage19.
17

Axis C1004-E Specifications

General

Bass reflex	Yes
Certification	EMC EN 55022 Class A, EN 55032 Class A, EN 50121-4, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KN24, KCC KN32 Class A, KN35 Safety IEC/EN/UL 60950-1, IEC/EN/UL 60950-22 Environment IEC/EN 60529 IP45, IEC/EN 62262 IK10, NEMA 250 Type 3R, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14
Product color	Black
Housing material	Metal, Plastic
Recommended usage	-
Speaker type	2-way
Driver diameter	120 mm
Tweeter diameter	25 mm
Number of drivers	1
Speaker enclosure	Reflex
Speaker placement	Wall-mountable
Audio output channels	- channels
Tweeter diameter (imperial)	0.98 \
Subwoofer driver diameter (imperial)	4.72 \
Amplifier class	D
Amplifier output power	6 W
Sensitivity	92 dB
Frequency range	60 - 20000 Hz
RMS rated power	- W
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Connectivity technology	Wired
Power source type	PoE
Power consumption (typical)	12.95 W
Packaging content	Installation Guide, A VHS authentication key, AXIS Camera Station license key, cable shoe, bracket with screws and washers, AXIS Connector Guard A
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	200 mm
Width	196 mm
Height	290 mm
Weight	3000 g
