Axis M7001 Installation Guide

Page 10 AXIS M7001 Installation Guide
AXIS Camera Management - multiple cameras/large installations
AXIS Camera Management can automatically find and set IP addresses, show connection status,
and manage firmware upgrades for multiple Axis video products.
Automatic discovery
1. Check that the encoder is connected to the network.
2. Start AXIS Camera Management. When the video encoder appears in the window, right-click
the link and select Live View Home Page.
3. See page 11 for instructions on how to set the password.
Assign an IP address in a single device
1. Select AXIS M7001 in AXIS Camera Management and click the
Assign IP button.
2. Select Assign the following IP address and enter the IP
address, the subnet mask and default router the device will
use.
3. Click the OK button.
Assign IP addresses in multiple devices
AXIS Camera Management speeds up the process of
assigning IP addresses to multiple devices, by
suggesting IP addresses from a specified range.
1. Select the devices you wish to configure (different
models can be selected) and click the Assign IP
button.
2. Select Assign the following IP address range and
enter the range of IP addresses, the subnet mask
and default router the devices will use.
3. Click Update. Suggested IP addresses are listed
under New IP Addresses and can be edited by
selecting a device and clicking the Edit button.
4. Click the OK button.

Axis M7001 Specifications

General

Cable length	1.5 m

Weight and Dimensions

Weight	82 g
Dimensions (WxDxH)	37.4 x 101 x 30.1 mm
