Page 6 AXIS M7001 Installation Guide
Hardware overview
Top view
Dimensions
HxWxD = 30 x 37 x 101 mm (1.2" x 1.5" x 4.0")
Weight = 82 g (0.2 lb)
Front view Rear view
RS-422/RS-485
connector
LED indicators for
power, status and
network
Mounting bracket
2.5 mm tele plug connector
BNC connector
75 Ohm
termination switch
Control button
Network connector (PoE class 2)
