Page 22 AXIS M7001 Guide d’installation
Vue d’ensemble du matériel
Vue de dessus
Dimensions
H x L x P = 30 x 37 x 101 mm
Poids = 82 g
Vue de face Vue de derrière
Connecteur RS-
422/RS-485
Témoins DEL
d’alimentation,
d’état et de
réseau
Support de fixation
Connecteur jack de 2,5 mm
Connecteur BNC
75 ohms
commutateur de terminaison
Bouton de commande
Connecteur réseau (PoE classe 2)
