Pagina 58 Guida all'installazione di AXIS M7001
Panoramica dell’hardware
Vista dall’alto
Dimensioni
A x L x P = 30 x 37 x 101 mm
Peso = 82 g
Vista anteriore Vista posteriore
Connettore RS-
422/RS-485
LED
alimentazione,
stato e rete
Staffa di montaggio
Connettore tele con spina da 2,5 mm
Connettore BNC
Interruttore di terminazione
da 75 Ohm
Pulsante di comando
Connettore di rete (PoE classe 2)
