AXIS M7014/M7010 Installation Guide Page 5
ENGLISH
AXIS M7014/M7010 Video Encoder
Installation Guide
This installation guide provides instructions for installing the AXIS M7014/M7010 video encoder on
your network. For all other aspects of using the product, please see the product’s User’s Manual,
available on the CD included in this package, or from www.axis.com
Installation steps
Follow these steps to install the AXIS M7014/M7010 on your local network (LAN):
1. Check the package contents against the list below.
2. Hardware overview. See page 6.
3. Install the hardware. See page 7.
4. Assign an IP address. See page 9.
5. Set the password. See page 12.
Package contents
Item Models/variants/notes
Axis video encoder models AXIS M7014
AXIS M7010
Power adapter models AXIS M7014: Type PS-K
AXIS M7010: Type PS-P
Mounting kit AXIS M7014
• 4 screws and 4 plugs to mount the encoder to a concrete wall
AXIS M7010
• 8 screws (for mounting with brackets)
• 2 mounting brackets
• 4 M6x20 screws for mounting in rack
AXIS M7014/M7010
• 4 Surface protection pads
• Terminal block connectors (RS-485/RS-422: 2 x 2-pin connector
for AXIS M7014; 8 x 2 pin connector for AXIS M7010, Power: 2-
pin connector)
CD AXIS Network Video Product CD, including product documentation,
installation tools and other software
Printed Materials AXIS M7014/M7010 Installation Guide (this document)
Axis Warranty Document
Important!
This product must be used in
compliance with local laws and
regulations.

Axis M7014 Specifications

General

Motion JPEG frame rate	15 fps
Maximum video resolution	720 x 576 pixels
PTZ control	Yes
Flash memory	128 MB
Image settings	Brightness, Color, Compression, Contrast, Mirroring, Privacy mask, Rotation
Internal memory	512 MB
Angle of rotation	270 °
Built-in processor	ARTPEC-4
Security algorithms	802.1x RADIUS
Supported network protocols	IPv4/v6, HTTP, HTTPS, IEEE 802.1X QoS 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
BNC input ports	4
I/O terminal ports	-
Ethernet LAN (RJ-45) ports	1
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Power requirements	8-20 V DC
Power consumption (typical)	7 W
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN61000-6-1, EN61000-6-2, EN 60950-1, C-tick AS/NZS CISPR 22, FCC Part 15 B B, ICES-003 B, VCCI B, KCC B, UL/IEC/EN 60950-1

Weight and Dimensions

Weight	570 g
Dimensions (WxDxH)	172 x 109 x 37 mm
