AXISP1367-ENetworkCamera
NO NO
NO
TICE TICE
TICE
Notpullingthecablebackcouldcausewatertoseepinanddamagetheproduct.
5.Makesurethatthecablegasketisttedproperly.
6.Ifconnectinganauxiliarydevice,forexampleanI/O,audio,orexternalpowerdevice,to
thecamera,repeatthestepsaboveasapplicabletothespecicdevice.
NO NO
NO
TICE TICE
TICE
Mounttheconnectorsafterthecablesarepushedthroughthecablegasket.
1
Bottomcover
2
ScrewT20(4x)
3
Wallbracket
4
BracketadjustmentscrewT30
7.Putthebottomcoveronthewallmountandtightenthescrews(torque2Nm).
16
