AXISP33/-VSeriesFixedDomeNetworkCamera
ConnectionDiagrams
I/OConnector
1
2
3
4
1
0VDC(-)
2
DCoutput3.3V,max50mA
3
Digitalinput0tomax40VDC
4
Digitaloutput0tomax40VDC,opendrain,100mA
InstalltheHardware
Note
•ThisAxisproductcanbemountedwiththecablesroutedthroughoralongthewall.
•Thisproductcanbettedwithametalconduitforprotectingthecablingwhenthe
cablesareroutedalongthewall.
