Page 6
AXIS
P7224 Installation Guide
Hardware overview
Dimensions
30 x 129 x 255 mm (1.2” x 5.1” x 10.0”) including connectors.
Part number (P/N) & Serial number (S/N).
The serial number may be required during
the installation.
Audio mounting nut
Audio input 1
Audio input 2
Audio output 1
Status LED
Power LED
Reset button
Control button
4 video inputs
Bus connectors
5
7
