Axis P9106-V User Manual

AXISP9106-VNetworkCamera
Additionalsettings
Setupnetworkstorage
Tostorerecordingsonthenetwork,youneedtosetupnetworkstorage:
1.GotoSettings>System>Storage.
2.ClickSetupunderNetworkstorage.
3.EntertheIPaddressofthehostserver.
4.Enterthenameofthesharedlocationonthehostserver.
5.Movetheswitchifthesharerequiresalogin,andenterusernameandpassword.
6.ClickConnect.
Events
Setuprulesandalerts
Youcancreaterulestomakeyourdeviceperformanactionwhencertaineventsoccur.Aruleconsistsofconditionsandactions.
Theconditionscanbeusedtotriggertheactions.Forexample,thedevicecanstartarecordingorsendanemailwhenitdetects
motion,orshowanoverlaytextwhenitrecords.
Triggeranaction
1.GotoSettings>System>Eventstosetuparule.Theruledeneswhenthecamerawillperformcertainactions.Rules
canbesetupasscheduled,recurring,orforexample,triggeredbymotiondetection.
2.SelecttheConditionthatmustbemettotriggertheaction.Ifyouspecifymorethanoneconditionfortherule,allofthe
conditionsmustbemettotriggertheaction.
3.SelectwhichActionthecamerashouldperformwhentheconditionsaremet.
Note
Ifyoumakechangestoanactiverule,thentheruleneedstoberestartedforthechangestotakeeffect.
Recordvideowhenthecameradetectsmotion
ThisexampleexplainshowtosetupthecameratostartrecordingtotheSDcardvesecondsbeforeitdetectsmotionandto
stoponeminuteafter.
MakesurethatAXISVideoMotionDetectionisrunning:
1.GotoSettings>Apps>AXISVideoMotionDetection.
2.Starttheapplicationifitisnotalreadyrunning.
3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.
Createarule:
1.GotoSettings>System>Eventsandaddarule.
2.Typeanamefortherule.
3.Inthelistofconditions,underApplication,selectAXISVideoMotionDetection(VMD).
4.Inthelistofactions,underRecordings,selectRecordvideowhiletheruleisactive.
5.Selectanexistingstreamproleorcreateanewone.
6.Settheprebuffertimeto5seconds.
12

Axis P9106-V Specifications

General

IK code	IK10
Form factor	-
Mounting type	Ceiling/wall
Product color	Black, White
Housing material	Aluminium, Zinc
Protection features	Dust resistant, Waterproof
International Protection (IP) code	IP66
Sensor type	CMOS
Progressive scan	Yes
Number of sensors	1
Optical sensor size	1/3 \
Fixed focal length	1.8 mm
Maximum aperture number	2.4
Tilt angle range	-5 - 5 °
Camera shutter speed	1/32500 - 1/5 s
Minimum illumination	0.34 lx
Bit rate control	Variable Bit Rate (VBR)
Total megapixels	3 MP
Maximum resolution	2016 x 1512 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	AVC, M-JPEG, MPEG4
Supported graphics resolutions	320 x 240, 640 x 360, 1920 x 1080 (HD 1080)
Streaming method	Multicast
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3af, IEEE 802.3at
Supported network protocols	IPv4, IPv6 USGv6, HTTP, HTTPS , SSL/TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP
Type	IP security camera
PTZ modes	Digital PTZ
Certification	EN 55032 Class A, EN 55024, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class B, KC KN35, IEC/EN/UL 60950-1, IEC/EN 60529 IP66, IEC/EN 62262 Class IK10, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78 IEC 60721-3-5 5M3, NIST SP500-267
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POL, POR, RUS
Number of languages	12
Placement supported	Indoor
Connectivity technology	Wired
Built-in HDD	No
Flash memory	256 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Power source type	PoE
Power consumption (max)	3.2 W
Power consumption (typical)	2.8 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	15 - 85 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	122 mm
Width	146 mm
Height	92 mm
Weight	655 g
