Axis Q16 Series Installation Guide

AXISQ16NetworkCameraSeries
4.Re-tightenthezoomandfocuspullers.
5.ClickAutofocus.
HowtoadjustfocuswiththeFocusAssistant
Note
OnlyvalidforoptionalP-iris,DC-irisormanualirislenses.
•Theviewinfrontofthecamerashouldnotbechangedduringfocusadjustment.Ifthe
cameraismoved,orifangerorotherobjectisplacedinfrontofthelens,restartthe
procedure.
•Ifmovementsinfrontofthecameracannotbeavoided,theFocusAssistantshouldnot
beused.
1.Mountorplacethecamerasothatitcannotbemoved.
2.Loosenthezoompullerbyturningitanti-clockwise.Movethepullertosetthezoom
level.Retightenthezoompuller.
3.Setthecameratoitsextremedistant-focuspositionbylooseningthefocuspullerand
turningthefocusringfullyclockwise.
4.Pressandquicklyreleasethecontrolbutton.Whenthestatusindicatorashes,the
FocusAssistantisenabled.
5.Gentlyturnthefocusringanti-clockwiseuntilitstops.
6.Turnthefocusringslowlyclockwiseuntilthestatusindicatorashesgreen.
7.ToexittheFocusAssistant,pressthecontrolbutton.Ifyoucannotaccessthecontrol
button,theFocusAssistantisswitchedoffautomaticallyafter15minutes.
8.Re-tightenthefocuspuller.
9.GototheImagetabintheproduct'swebpage.
10.ClickAutofocusandfollowtheinstructionsfromthewizard.
11
EN
