AXISQ16NetworkCameraSeries
Leportsériepeutêtrecongurépourlapriseencharge
de:
•RS485semi-duplexsurdeuxls
•RS485duplexintégralsurquatrels
•RS422simplexsurdeuxls
•RS422duplexintégralsurquatrelspour
communicationpointàpoint
FonctionBro-
che
Notes
RS485Balt
RS485/422RX(B)
1
RS485Aalt
RS485/422RX(A)
2
PaireRXpourtouslesmodes(RX/TXcombinépourRS485à
2ls)
RS485/RS422TX(B)
3
RS485/RS422TX(A)
4
PaireTXpourRS422etRS485à4ls
Important
Lalongueurmaximaledecâbleestde30mètres(98pieds).
38
