Axis Q1755 Installation Guide

AXIS Q1755 Installation Guide Page 3
ENGLISH
AXIS Q1755 Installation Guide
This installation guide provides instructions for installing the AXIS Q1755 Network Camera on your
network. For all other aspects of using the product, please see the User’s Manual, available on the
CD included in this package, or from www.axis.com/techsup
Installation steps
1. Check the package contents against the list below.
2. Hardware overview. See page 4.
3. Install the hardware. See page 5.
4. Assign an IP address. See page 6.
5. Set the password. See page 9.
Package contents
Item Models/variants/notes
Network camera AXIS Q1755 50Hz/60Hz
Terminal block connector (1) 4-pin connector for connecting external devices to the I/O terminal
connector
(1) 3-pin connector for power connection
(2) 2-pin connector for RS-485/422 connection
Camera stand Metal stand supplied with mounting screws
CD AXIS Network Video Product CD, including product documentation,
installation tools and other software
Printed materials AXIS Q1755 Installation Guide (this document)
Axis Warranty Document
Optional accessories See www.axis.com for information on power accessories and outdoor housings
Important!
This product must be used in
compliance with local laws and
regulations.

Axis Q1755 Specifications

General

Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/10000 - 1/2 s
Minimum illumination	2 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, Pelco-D
Power source type	PoE
Power over Ethernet (PoE)	Yes
Power consumption (typical)	17.4 W
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	186 x 85 x 211.4 mm
Power requirements	20 - 24 V AC
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B, Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B
Processor model	ARTPEC-3
Flash memory	256 MB
Internal memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	985 g
