AXIS Q60-S Series
Green Shows steady green for 10 seconds for normal operation after
startup completed.
Amber
Steady during startup. Flashes during rmware upgrade.
Amber/Red Flashes amber/red if network connection is unavailable or lost.
Red Flashes red for rmware upgrade failure.
Media Converter Switch LED Indicators
LED
Color
Indication
Power Unlit
DC power unconnected or current protection engaged (power
overload)
Green DC power connected.
Network (4x)
Amber 10 Mbit connection. Flashes during activity.
Green
100/1000 Mbit connection. Flashes during activity.
Camera Green
100 Mbit connection. Flashes during activity.
Connectors and Buttons
For specications and operating conditions, see page 18.
Network Connector
NONO
NO
TICETICE
TICE
The product shall be connected using a shielded network cable (STP). All cables connecting
the product to the network shall be intended for their specic use. Make sure that the
network devices are installed in accordance with the manufacturer’s instructions. For
information about regulatory requirements, see Electromagnetic Compatibility (EMC) on
page 2.
Multi-connector
Terminal connector for connecting the supplied media converter switch, which provides the
following signals:
• DC Power
• Network (Ethernet 10/100Base-T)
• Input/Output (I/O)
The supplied multi-connector cable is required in order to maintain the product’s NEMA/IP rating.
For more information, see Multi-Connector Cable on page 15.
14
