AXIS Q60-S Series
Install the Hardware
NONO
NO
TICETICE
TICE
• Due to local regulations or the environmental and electrical conditions in which the
product is to be used, a shielded network cable (STP) may be appropriate or required.
All cables connecting the product to the network and that are routed outdoors or in
demanding electrical environments shall be intended for their specic use. Make sure that
the network devices are installed in accordance with the manufacturer’s instructions. For
information about regulatory requirements, see Regulatory Information on page 2.
• Mount the product with the dome cover facing downward.
• Be careful not to scratch, damage or leave ngerprints on the dome cover because this
could decrease image quality. If possible, keep the protective plastic on the dome cover
until the installation is complete.
The Axis product can be installed with the cables routed through or along the wall or roof.
Read all the instructions before installing the product. Some installation steps would benet from
being completed together because they require removal of the dome cover.
A hardware installation can include the following:
• The product is supplied with a clear dome cover (premounted). A smoked dome cover is
available as an accessory. To replace the dome cover, see page 22.
• A standard or high capacity SD card (not included) can be used to store recordings locally
in the product. To install an SD card, see page 23.
• To install the product using a T91C61 Wall Mount (sold separately), see page 29.
Attach the Sunshield
Attaching the sunshield is optional. The sunshield helps keep the temperature inside the camera
down.
1. Remove the screw plugs from the camera unit.
2. Place the sunshield on the camera unit.
3. Secure the sunshield using the supplied screws.
Replace the Dome Cover
Replacing the dome cover is only necessary if you want to use a smoked dome cover or if the
dome cover is scratched or damaged. Smoked dome covers and spare clear dome covers can be
purchased from your Axis reseller.
Use the Installation Guide delivered with the dome cover.
22
