AXIS Q60-S Series
1
Power LED indicator
2
Network LED indicator (4x) ETH 1/2/3/4
3
Camera LED indicator
Install the Network Camera
NONO
NO
TICETICE
TICE
To comply with the IP66-rated design of the camera and maintain the IP66 protection, the
supplied multi-connector cable shall be used.
1. Install the selected bracket (sold separately) according to the instructions supplied with
the bracket. If drilling is required, make sure to use drill bits, screws, and plugs that are
appropriate for the material. See www.axis.com for information on available mounting
accessories.
2. Route the multi-connector cable through the holes in the mounting bracket.
3. Secure the camera using the supplied safety wire.
29
