Axis Q6315-LE User Manual

AXISQ6315-LEPTZCamera
Configureyourdevice
3.ClickAddpresetpositiontocreateanewpresetposition.
Adjustthecameraview(PTZ)
Tolearnmoreaboutdifferentpan,tilt,andzoomsettings,seePan,tilt,andzoom(PTZ)onpage49.
1.GotoPTZ>Limits.
2.Setthelimitsasneeded.
Createarecordedguardtour
1.GotoPTZ>Guardtours.
2.Click
Guardtour.
3.SelectRecordedandclickCreate.
4.Enteranamefortheguardtourandspecifythepauselengthbetweeneachtour.
5.ClickStartrecordingtourtostartrecordingthepan/tilt/zoommovements.
6.Whenyou’resatised,clickStoprecordingtour.
7.ClickDone.
8.Toscheduletheguardtour,gotoSystem>Events.
Viewandrecordvideo
Thissectionincludesinstructionsaboutconguringyourdevice.Tolearnmoreabouthowstreamingandstorageworks,goto
Streamingandstorageonpage50.
Reducebandwidthandstorage
Important
Reducingthebandwidthcanresultinlossofdetailsintheimage.
1.GotoVideo>Stream.
2.Click
intheliveview.
3.SelectVideoformatH.264.
4.GotoVideo>Stream>GeneralandincreaseCompression.
5.GotoVideo>Stream>Zipstreamanddooneormoreofthefollowing:
-SelecttheZipstreamStrengththatyouwanttouse.
Note
TheZipstreamsettingsareusedforbothH.264andH.265.
-TurnonDynamicFPS.
-TurnonDynamicGOPandsetahighUpperlimitGOPlengthvalue.
9

Axis Q6315-LE Specifications

General

Pan Range	360° endless
Day/Night Functionality	Yes
IK Rating	IK10
Resolution	1920x1080
Optical Zoom	31x
Infrared Illumination	Up to 250 meters
Power over Ethernet (PoE)	Yes
Weather Resistance	IP66, NEMA 4X
Image Sensor	1/2.8" progressive scan CMOS
Video Compression	H.264, H.265, MJPEG
Frame Rate	Up to 60 fps
Audio Compression	AAC, G.711, G.726
Audio Input/Output	1 input, 1 output
Network Protocols	IPv4, IPv6, HTTP, HTTPS, FTP, SMTP
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication, user access log
Edge Storage	microSD/microSDHC/microSDXC slot
Operating Conditions	-40°C to 50°C (-40°F to 122°F)
Power	Max 25.5 W
ONVIF	Profile S, G, T
