AXISCameraStationS22ApplianceSeries
Setupexamples
Connectorsused
PoEenablednetworkconnectors,port1-12
USB2.0connectorx2(forkeyboardandmouse)
Displayport
TM
orHDMIconnector
ConnectorsNOTused
RJ45switchuplink(U1)
SFPswitchuplink(U1)
RJ45serveruplink(U2)
USB3.0connector(frontside)
Audiolinein(frontside)
Audiolineout(frontside)
Setupinanexistingnetwork
Youcancreateasurveillancenetworkwithinanexistingnetwork.Thismeansthatthesurveillancenetworkisseparatedfrom
theexistingnetwork.
Note
Whenyouuseanadditionalrecorder,forexample,theAXISS30Recorders,theappliancedoesnotroutenetworkdatafrom
thesurveillancenetworktotheservernetworkforrecording.MakesurethattheAXISS30Recordersareconnectedto
thesamenetworkasthecameras.
