Setupexamples
IP: xxx.xxx.xxx.xxx
IP: 192.168.0.xxx
IP: 192.168.0.xxx
U2U1
Difcultylevel
Advanced
BenetsAbilitytouseanAXISCameraStationclienttoconnecttoS22
seriesoverthenetwork.
Networksegregation
LimitationsMayrequireyoutofollowcorporatenetworkpolices
Actionsneeded
Changethedefaultpasswordforthebuilt-inswitch
RegistertheAXISCameraStationlicense
Connectorsused
PoEenablednetworkconnectors,port1-12
RJ45serveruplink(U2)forconnectiontonetwork
(Optional)USB2.0connectorx2(forkeyboardandmouse)
(Optional)Displayport
TM
orHDMIconnector
ConnectorsNOTused
RJ45switchuplink(U1)
SFPswitchuplink(U1)
USB3.0connector(frontside)
Audiolinein(frontside)
