Axis Video Server User Manual

66
Axis video server - Technical specifications
Technical specifications
Item Specification
Models • AXIS 241S: 1-channel video server
• AXIS 241Q: 4-channel video server
• AXIS 241SA: 1-channel video server with audio
• AXIS 241QA: 4-channel video server with audio
• AXIS 242S IV: 1-channel video server with support for Intelligent Video
Video compression • Motion-JPEG, including single snapshot JPEG images.
• MPEG-4 Part2 (ISO/IEC 14496-2), Profiles: ASP and SP
Resolutions • 4CIF, 2CIF Expanded, 2CIF, CIF, QCIF
• Maximum 768x576 (PAL) 704x480 (NTSC)
• Minimum 176x144 (PAL) 160x120 (NTSC)
Frame rates • Motion JPEG: up to 25/30 (PAL/NTSC) fps in 4CIF (1 channel),
up to 25/30 fps (PAL/NTSC)in CIF (4 channels)
• MPEG-4: up to 25/30 (PAL/NTSC) fps in 2CIF (1 channel),
up to 17/20 (PAL/NTSC) fps in CIF (4 channels)
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and total bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Compression levels: 11 (Motion JPEG), 23 (MPEG-4)
• Rotation: 90
o
, 180
o
, 270
o
• Aspect ratio correction
• Color and black/white
• Overlays: time, date, text, image
Audio features
(AXIS 241QA
AXIS 241SA)
Full-duplex audio. Select the encoding format from System Options:
ADPCM format at 24kbps, 8 kHz sampling (G.726 - select G723 from drop-down list)
ADPCM format at 32kbps, 8 kHz sampling (G.726 - select G721 from drop-down list)
PCM µ−law format at 64kbps, 8 kHz sampling (G.711 default)
Security • Multiple user levels with password protection
• IP address filtering
• HTTPS encryption
Users • 20 simultaneous viewers for Motion JPEG and/or unicast MPEG-4
• More than 20 viewers possible when using MPEG-4 multicast
Alarm and event
management
• Events triggered by built-in multi-window motion detection, external inputs or
according to set schedule
• Image uploads via FTP, email and HTTP
• Event notification via TCP, email, HTTP and external outputs
• Pre- and post-alarm buffer of 9 MB per channel (approx 4 min CIF video at 4 fps)
Pan/Tilt/Zoom • Drivers for all supported PTZ units available from www.axis.com
• PTZ control queuing capability

Axis Video Server Specifications

General

Operating Temperature	0 °C to 50 °C (32 °F to 122 °F)
Video Compression	H.264, MJPEG, MPEG-4
Network Interface	10/100 Mbps Ethernet
Dimensions	Varies by model
Weight	Varies by model
