Axpert VM-1000 - Quick Start Troubleshooting

维修手册
专案名称：
AxpertVM1KW/VM2KW
专案编号：
S1701112
修订版次：
00 PAGE 20/30
V-RDP-004-73 A
Fault code 03
Battery is over-charged. Return to repair center.
The battery voltage is too high.
Check if spec and
quantity of batteries are
meet requirements.
Fault code 01 Fan fault Replace the fan.
Fault code 06/58
Output abnormal (Inverter voltage
below than 190Vac or is higher
than 260Vac)
1. Reduce the connected
load.
2. Return to repair
center
Fault code
08/09/53/57
Internal components failed. Return to repair center.
Fault code 51 Over current or surge.
Restart the unit, if the
error happens again,
please return to repair
center.
Fault code 52 Bus voltage is too low.
Fault code 55 Output voltage is unbalanced.
Fault code 56
Battery is not connected well or
fuse is burnt.
If the battery is
connected well, please
return to repair center.
6.4 Quick start
Before any detail check of the system, please check the components listed as follow table.
NOTE: It is important to check the capacitor’s voltage on the board lower than the safety voltage before
any check action.
Functional
block
Checked components
Instruction
function
Reference
value
Failed status
DC-DC
Converter
Fuse F1 Resistance 0.14 ohm short or open
MOSFET：
CSD19505KCS VM-2000
IRFB3306GPBF VM-1000
Q2---Q4
Q9---Q11
Resistance
310k DS short or open
290k GD short or open
5k GS short or open
Diode: RHRP1560 VM-2000
BYC8-600P VM-1000
D17---D20 Resistance
165k short or open
Resistance
R6-R9，R13-R15
R21
Resistance
10 ohm short or open
DC-AC
Inverter
IGBT:
STGW60H65DFB VM-2000
STGW30H60DFB VM-1000
Q16---Q19 Resistance
178K-200K DS short or open
220K-250K
GD short or open
50K GS short or open
Resistance R54,R56,R61,R64 Resistance
33 ohm short or open
