Axxess AXDIS-CL2 User Manual

9
REV. 1/21/2020 INSTAXDIS-CL2
• Listed below are the advanced menu options:
• Show Text – Exits menu.
• Set Tuning Mode – Allows the user to select tuning by preset or channel.
• Set Preset – Allows the user to program presets.
• Set Display – Allows the user to choose which satellite radio information should be
displayed.
Note: If using the AX-LCD, SEEK UP controls the top line on the display; SEEK DOWN the
bottom line.
• Set Satellite Radio Text Mode - Allows the user to set the display length of the satellite
radio information. Options are; On, Off, or 5 seconds (default is 5 seconds).
• To access AUX-IN or rear seat entertainment, press and hold the SOURCE button on the
steering wheel for 2 seconds. This will switch to the next source available. Each time the
SOURCE button is pressed for 2 seconds the source will change. The sequence of sources are
SAT/RSE/AUX-IN. The AX-LCD will provide a visual confirmation of what source you are on.
EXTRA FEATURES (CONT)
STEERING WHEEL CONTROL SETTINGS
L.E.D. feedback
The (18) Red L.E.D. flashes represent what brand radio the AXDIS-CL2 believes it is connected
to. Each flash represents a different radio manufacturer. For example, if you are installing
a JVC radio, the AXDIS-CL2 will flash (5) times. Following is a legend that dictates which
manufacturer corresponds to which flash.
L.E.D. feedback legend
* Note: If the AXDIS-CL2 flashes Red (7) times, and you do not have an Alpine radio connected to
it, that means the AXDIS-CL2 does not detect a radio connected it. Verify that the 3.5mm jack is
connected to the correct steering wheel jack/wire in the radio.
** Note: Part number AXSWCH-PAR is required (sold separately). Also, the Parrot radio must be
updated to rev. 2.1.4 or higher through www.parrot.com.
† Note: If you have a Clarion radio and the steering wheel controls do not work, change the radio
type to the other Clarion radio type; same for Eclipse. The following section explains how to do this.
‡ Note: If you have a Kenwood radio and the L.E.D. feedback comes back as showing as a JVC radio,
change the radio type to a Kenwood. The following section explains how to do this.
1 flash - Eclipse (Type 1) †
2 flashes - Kenwood ‡
3 flashes - Clarion (Type 1) †
4 flashes - Sony / Dual
5 flashes - JVC
6 flashes - Pioneer / Jensen
7 flashes - Alpine *
8 flashes - Visteon
9 flashes - Valor
10 flashes - Clarion (Type 2) †
11 flashes - Metra OE
12 flashes - Eclipse (Type 2) †
13 flashes - LG
14 flashes - Parrot **
15 flashes - XITE
16 flashes - Philips
17 flashes - TBD
18 flashes - JBL
Continued on the next page
