AX SWC
Remapping
REV. 2/17/20© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
After the AXSWC interface has been programmed and functioning properly, the button assignment for the steering wheel controls may be reassigned. For example, Seek Down may be preferred
to be Mute instead. This feature can be performed by either following the steps below, through a Windows based computer using the Axxess Updater, or through the Axxess Updater app
available from the Android/Apple mobile devices app store.
Note: Apple mobile devices will require the use of the
AXHUB-1
for this feature.
Attention! If more than 20 seconds elapses between steps, the procedure will abort, and the light in the interface will go out. The interface may not function properly and may need to be
reset and reprogrammed.
1. Cycle the ignition on and wait until the light flashes Green 1 time then goes out.
2. Immediately press and hold the Volume Up button on the steering wheel until the light turns solid Green, then release. The light will then go out indicating
Volume Up
has now
been programmed.
3.
Press and hold the Volume Down button on the steering wheel until the light turns solid Green, then release. The light will then go out indicating Volume Down has now been
programmed
.
4. Continue from Seek Up / Next in the Button Function Legend to reference the order in which the steering wheel control buttons must be programmed.
Note: If a function in the legend is not present on the steering wheel, press the Volume Up button on the steering wheel until the light turns solid Green, then release. This will
tell the interface to skip that function.
5. To complete the remapping process, press and hold the Volume Up button on the steering wheel until the light turns solid Green, then goes out. Release the Volume Up button
at this point. The remapping process is now complete.
Button Function Legend
Function # Function
1 Volume Up
2 Volume Down
3 Seek Up / Next
4 Seek Down / Previous
5 Source / Mode
6 Mute
7 Preset Up
8 Preset Down
9 Power
Function # Function
10 Band
11 Play / Enter
12 PTT (push to talk)
13 On Hook
14 Off Hook
15 Fan Up *
16 Fan Down *
17 Temp Up *
18 Temp Down *
* Not applicable in this application
Note: Certain radios may not have these commands. Please refer to the manual provided
with the radio, or contact the radio Manufacturer for specific commands recognized by
that particular radio.
