Connections to be made
From the 16-pin harness to the aftermarket radio:
• Connect the Red wire to the accessory wire.
• Connect the Orange/White wire to the illumination wire. If the aftermarket
radio has no illumination wire just tape off the Orange/White wire.
• If equipped with a factory amplifier, connect the Blue/White wire to the amp
turn on wire.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the Brown wire to the mute wire. If the aftermarket radio does not
have a Mute wire, tape up the Brown wire.
The following (3) wires are only for multimedia/navigation radios that require these wires
.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
From the 18-pin harness to the aftermarket radio:
• Connect the Black wire with the ring terminal to the radio chassis with the ISO
screw that is supplied with radio.
Note: This wire must be connected as instructed otherwise the interface
will not be functional.
• The Black/Yellow wire will be discussed later in this manual.
• If the vehicle does not come equipped with steering wheel controls, connect
the Green/Orange wire to the Green/Orange wire on the ASWC-STALK (sold
separately) to retain the personalization features. See the “No OE Steering
Wheel Controls” section for more information and wiring of the ASWC-STALK.
From the 44-pin harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Green wire to the left rear positive speaker output.
Continued on the next page
