Ayra ComPar KIT 3 - DMX Channel Modes and Values; 1, 3, and 7 Channel Modes

This unit has the following DMX channels and DMX values:
1 Channel Mode
CH1 Chase 000-007 Blackout
008-037 Show 01
038-067 Show 02
068-097 Show 03
098-127 Show 04
128-157 Show 05
158-187 Show 06
188-217 Show 07
218-247 Show 08
248-255 Random Show 01-08
3 Channel Mode
CH1 Red 000-255 Dimmer 0-100%
CH2 Green 000-255 Dimmer 0-100%
CH3 Blue 000-255 Dimmer 0-100%
7 Channel Mode
CH1 Red 000-255 Dimmer 0-100%
CH2 Green 000-255 Dimmer 0-100%
CH3 Blue 000-255 Dimmer 0-100%
CH4 Dimmer 000-255 Dimmer 0-100%
CH5
Strobe
000-007 No function
008-247 Strobe slow to fast
248-255 Sound strobe
CH6
Colour chase
000-007 Manual colour mix
008-022 Colour chase 1
023-037 Colour chase 2
038-052 Colour chase 3
053-067 Colour chase 4
068-082 Colour chase 5
083-097 Colour chase 6
098-112 Colour chase 7
113-127 Colour chase 8
128-142 Colour chase 9
143-157 Colour chase 10
158-172 Colour chase 11
173-187 Colour chase 12
188-202 Colour chase 13
203-217 Colour chase 14
218-232 Colour chase 15
233-247 Colour chase 16
248-255 Stand-alone
CH7
Speed
000-007 Hold
008-255 Speed slow to fast
12Channel Mode
CH1 Red 1 000-255 Dimmer 0-100%
CH2 Green 1 000-255 Dimmer 0-100%
CH3 Blue 1 000-255 Dimmer 0-100%
