Chapter 1. OVERVIEW
2
Certification ●
Gas Appliance Directive (CE)*: 0063BS1427(with AUR450C and Q241A104)
0063CN6671(with RX-R4_C series)
UL: File No. MH27717
CSA: Master Report LR 078402
* CE marking appears only on the controller.
Note. Certification does not apply to AUD300C1_ 0Y and AUD300C1_0YT.
Combined burner controller ●
Model No. Description
RX-R40, RX-R44, RX-R46 Burner Control Module
AUR300C, AUR350C Advanced Ultraviolet Burner Controller
AUR450C Dynamic Self-Checking Burner Controller
Maintenance/optional parts ●
Model No. Description
AUD60A1000 AUD Maintenance Kit *
1
81446924-001 Flange unit (Standard type)
81446924-101 Flange unit (Condenser type)
81447495-001 Nut packing
81447509-001 Bushing 1 × 3/4
FSP136A100 Analog flame meter
*1 AUD Maintenance Kit AUD60A1000
The AUD Maintenance Kit incorporates the tube and shutter units, including expend-
ables like the expiration date label*
2
and the O-ring used for sealing between the
flange and cover of the AUD.
Terminals for shutter
driver connection
(White lead wire)
Tube unit
Shutter unit
Label
Thermo-label
G terminal (Yellow lead wire)
F terminal (Blue lead wire)
Tube unit
retaining screws (2)
Position of the expiration date label
*2 Expiration date label
