Azbil MQV9020 - Flow Rate Range

5-18
Chapter 5. ADVANCED OPERATION
5-4 Flow Rate Range
The flow rate range can be reduced to a level of 99% down to 10% of the standard range using
the flow rate range setup (
C-24
or
C-25
). However, the minimum control flow rate is the same
as for the standard range. As the range is reduced, the setup and display resolution levels are im-
proved as described in the table below.
Setup and display resolution levels after changing of range
MQV9020 MQV9050 MQV9500 MQV0005 MQV0010
Full scale
flow rate
[mL/min]
Resolution
[mL/min]
Full scale
flow rate
[mL/min]
Resolution
[mL/min]
Full scale
flow rate
[L/min]
Resolution
[L/min]
Full scale
flow rate
[L/min]
Resolution
[L/min]
Full scale
flow rate
[L/min]
Resolution
[L/min]
− − 50.0–30.2 0.2 0.500–0.302 0.002 5.00–3.02 0.02 − −
20.0–12.1 0.1 30.0–12.1 0.1 0.300–0.121 0.001 3.00–1.21 0.01 − −
12.00–6.05 0.05 12.00–6.05 0.05 (120.0–
60.5)
(0.5) 1.200–0.605 0.005 10.00–6.05 0.05
6.00–3.02 0.02 6.00–3.02 0.02 (60.0–30.2) (0.2) 0.600–0.302 0.002 6.00–3.02 0.02
3.00–1.00 0.01 3.00–1.00 0.01 (30.0–10.0) (0.1) 0.300–0.100 0.001 3.00–1.00 0.01
MQV0050 MQV0200
Full scale
flow rate
[L/min]
Resolution
[L/min]
Full scale
flow rate
[L/min]
Resolution
[L/min]
50.0–30.2 0.2 − −
30.0–12.1 0.1 200–121 1
12.0–6.05 0.05 120.0–60.5 0.5
6.00–3.02 0.02 60.0–30.2 0.2
3.00–1.00 0.01 30.0–10.0 0.1
Note: The display unit of the flow rate shown in ( ) for the MQV9500 is mL/min.
Handling Precautions
•
Even after flow rate range is changed, the accuracy specifications
are the same as for the standard range. (The full scale designated
by % FS shows the numeric value of the standard range.)
•
Even though the flow rate range is changed, the minimum control
flow rate is the same as for the standard range.
•
Analog input/output scaling is changed automatically so that the
flow rate range after the change is shown as full scale (FS).
